ZA 13 MOULD WT 45 (3,5+3,5KG)

ZA 13 MOULD WT 45 (3,5+3,5KG)
Gross: 208.309 EUR/pcs
Weights (kg) select:

13 Shore A of transparent is a bicomponent (base and catalyst) addition RTV silicon rubber that vulcanizes at room temperature. Indicated for the duplication of models with small recesses.



Mould-making and Concrete moulding for its remarkable reproduction accuracy, high dimensional stability and high mechanical strength.

  • Chemical and Physical Properties

    Vulcanized product

    Mixing ratio 1 : 1

    Viscosity of pre-catalyzation mixture 4500 ± 500 cP

    Mixing time at 23 °C (73 °F) 1’

    Working time at 23 °C (73 °F) WT= 40’ – 50’

    Setting time at 23 °C (73 °F) ST= 6 – 7 h

    Shore A hardness after 24 hours 13 ± 2 shA

    Breaking load 3.0 ± 0.2 N/mm2

    Elongation at break 450±20 %

    Tear strength (DIE B) >10 ± 1 N/mm

    Tear strength (DIE C) >9 ± 1 N/mm

    Dimensional vartation after 24 hours < 0.05 %

  • Hardness
    13±2 shA
    Processing time
    40-50 perc
    Curing time (Hours)
    6-7 óra
    Weight
    7.7 kg/pcs
